Rated power measured according to DIN 45500 up to 1% distortion factor in 13,5V
Steg K4.01
1 × 88 watts, channel 1 at 4 Ohm
2 × 88 watts, channel 1 + 2 at 4 Ohm
4 × 88 watts, channel 1 up to 4 at 4 Ohm
Current consumption 40,4A
efficiency 64,8%
1 × 327 watts, channel 1 + 2 bridged at 4 Ohm
2 × 327 watts, channel 1 + 2 and 3 + 4 bridged at 4 Ohm with 13,4V supply voltage
Current consumption 85,5A
efficiency 57,2%
1 × 545 watts, channel 1 + 2 bridged at 2 Ohm
2 × 493 watts, channel 1 + 2 and 3 + 4 bridged at 2 Ohm with 13,3V supply voltage
Current consumption 148A
efficiency 50,1%
986 watts total power
Rated power measured according to DIN 45500 up to 1% distortion factor in 13,5V
Steg K4.01
1 × 89 watts, channel 1 at 4 Ohm
2 × 89 watts, channel 1 + 2 at 4 Ohm
4 × 89 watts, channel 1 up to 4 at 4 Ohm
Current consumption 40,4A
efficiency 65,5%
1 × 331 watts, channel 1 + 2 bridged at 4 Ohm
2 × 331 watts, channel 1 + 2 and 3 + 4 bridged at 4 Ohm with 13,4V supply voltage
Current consumption 84,7A
efficiency 58,4%
1 × 564 watts, channel 1 + 2 bridged at 2 Ohm
2 × 499 watts, channel 1 + 2 and 3 + 4 bridged at 2 Ohm with 13,3V supply voltage
Current consumption 149A
efficiency 50,4%
998 watts total power
Rated power measured according to DIN 45500 up to 1% distortion factor in 13,5V
Steg K4.01
1 × 90 watts, channel 1 at 4 Ohm
2 × 90 watts, channel 1 + 2 at 4 Ohm
4 × 90 watts, channel 1 up to 4 at 4 Ohm
Current consumption 41,6A
efficiency 64,3%
1 × 335 watts, channel 1 + 2 bridged at 4 Ohm
2 × 331 watts, channel 1 + 2 and 3 + 4 bridged at 4 Ohm with 13,4V supply voltage
Current consumption 85A
efficiency 58,2%
1 × 558 watts, channel 1 + 2 bridged at 2 Ohm
2 × 512 watts, channel 1 + 2 and 3 + 4 bridged at 2 Ohm with 13,3V supply voltage
Current consumption 155A
efficiency 49,7%
1024 watts total power
Rated power measured according to DIN 45500 up to 1% distortion factor in 13,5V
Steg K4.01
1 × 89 watts, channel 1 at 4 Ohm
2 × 89 watts, channel 1 + 2 at 4 Ohm
4 × 89 watts, channel 1 up to 4 at 4 Ohm
Current consumption 41,2A
efficiency 64,2%
1 × 324 watts, channel 1 + 2 bridged at 4 Ohm
2 × 324 watts, channel 1 + 2 and 3 + 4 bridged at 4 Ohm with 13,4V supply voltage
Current consumption 85A
efficiency 56,9%
1 × 564 watts, channel 1 + 2 bridged at 2 Ohm
2 × 487 watts, channel 1 + 2 and 3 + 4 bridged at 2 Ohm with 13,3V supply voltage
Current consumption 152A
efficiency 48,2%
974 watts total power
Rated power measured according to DIN 45500 up to 1% distortion factor in 13,5V
Steg K4.01
1 × 89 watts, channel 1 at 4 Ohm
2 × 89 watts, channel 1 + 2 at 4 Ohm
4 × 89 watts, channel 1 up to 4 at 4 Ohm
Current consumption 41,6A
efficiency 63,6%
1 × 328 watts, channel 1 + 2 bridged at 4 Ohm
2 × 328 watts, channel 1 + 2 and 3 + 4 bridged at 4 Ohm with 13,4V supply voltage
Current consumption 85,8A
efficiency 57%
1 × 571 watts, channel 1 + 2 bridged at 2 Ohm
2 × 506 watts, channel 1 + 2 and 3 + 4 bridged at 2 Ohm with 13,3V supply voltage
Current consumption 154,8A
efficiency 49,1%
1012 watts total power
