Rated power measured according to DIN 45500 up to 1% distortion factor in 13,5V

Rodek R680N

1 × 119 watts, channel 1 at 4 Ohm
2 × 113 watts, channel 1 + 2 at 4 Ohm
4 × 105 watts, channel 1 up to 4 at 4 Ohm
6 × 98 Watts channel 1 up to 6 at 4 Ohm with 13,4V supply voltage
Current consumption 69A
efficiency 63,6%

1 × 369 watts, channel 1 + 2 bridged at 4 Ohm with 13,8V supply voltage
2 × 328 watts, channel 1 + 2 and 3 + 4 bridged at 4 Ohm with 13,7V supply voltage
3 × 292 watts, channel 1 up to 6 bridged at 4 Ohm with 13,6V supply voltage
Current consumption 115,2A
efficiency 56%

876 watts total power
